Pipe / Fitting Sizing

Date Posted:1 July 2022

To assist in pipe sizes, the following list provides the physical measurements to identify the correct pipe size.

PIPE SIZING


To assist in pipe sizes, the following list provides the physical measurements to identify the correct pipe size.

These measurements are of the EXTERNAL diameter of the pipe or hose (and spigot fittings, or internal diameter of socket fittings)

Pipe or Fitting             Actual External Diameter

1/2" / 15mm              -  21.4mm
3/4" / 20mm              -  26.8mm
1" / 25mm                 -  33.5mm
1.5" / 40mm              -  48.4mm
2" / 50mm                 -  60.5mm



These measurements are of the INTERNAL diameter of TUBING only:

3/8" / 9mm               -  9mm
3/4" / 19mm             -  19mm



External diameter of the barb fittings used with tubing is generally slightly larger than the bore of the tubing to ensure a tight fit.
